REPOLEN PIPE
PP-R BLUE LINE
MONOLAYER
Perfect for drinking water. Non-toxic, odorless, colorless and tasteless material.
Full guarantee in saline environments and excellent resistance to freezing.
Resistance to corrosion, pressure and high temperatures.
Prevents blockages by removing scale. Low pressure drop.
Recyclable material, very light and easy to install.
REPOLEN PP-R DRINKING WATER pipes are ideal for transporting pressurized cold and hot drinking water, thanks to their high mechanical and chemical resistance. Their distinctive blue line facilitates identification in plumbing installations, optimizing the assembly process. They comply with quality regulations and are made from 100% recyclable material.
Structure
MONOLAYER
Materials
PP-R
Colour
GREEN RAL 6024 WITH BLUE LINES
USES
REGULATIONS
UNE EN 15874:
Sistema de canalización en materiales plásticos para instalaciones de agua caliente y fría. Polipropileno (PP)
DIN 8077:
Tuberías de polipropileno. Dimensiones
DIN 8078:
Tuberías de polipropileno. Requerimientos generales de calidad y prueba
RP 001.16:
Sistema de canalización en materiales plásticos para instalaciones de agua caliente y fría
CTE:
Código Técnico de la Edificación
RD 03/2023:
Establece criterios sanitarios de la calidad del agua de consumo humano
Material PP-R
Densidad
905 kg/m3
MFI (230º.2.16Kg)
0.30 g/10min
Módulo de elasticidad
815 Mpa
Resistencia al impacto Charpy con entalla a 23ºC
> 9 kJ/m2
Resistencia a la tracción en el punto Yield
26 Mpa
Resistencia a la tracción en el punto de rotura
27 MPa
Alargamiento en el punto de rotura
> 520 %
VICAT (Temperatura de reblandecimiento) 9.8N
70 ºC
Coeficiente de conductividad térmica (λ)
0.24 w/m·K
HDT (Temperatura de deformación) 0.45 MPa
45ºC
Product
Estructura
MONOCAPA PP-R
Color
Verde RAL 6024 con 4 franjas azules
Reciclabilidad
100%
Retracción longitudinal
≤2%
Resistencia al impacto Charpy a 0ºC
<10% de rotura
Opacidad
Si
Rugosidad (k)
0.007 mm
Coeficiente de dilatación térmica lineal (α)
0.150 mm/mºC
Resistencia a la presión interna
20º
1h
16MPa
Sin roturas
95º
22h
4.3MPa
Sin roturas
95º
165h
3.8MPa
Sin roturas
95º
1000h
3.5MPa
Sin roturas
Estabilidad térmica mediante ensayo de presión
110ºC
8760h
1.9Mpa
Sin roturas| SDR | Code | d (mm) | di (mm) | e (mm) | Capacity (L/Mts) | Weight (kg/m) | Mts/Packages | Pallet Packages |
|---|---|---|---|---|---|---|---|---|
| 11 | 440000003 | 20 | 16.2 | 1.9 | 0.206 | 0.105 | 120 | 24 |
| 11 | 440000006 | 25 | 20.4 | 2.3 | 0.327 | 0.165 | 80 | 28 |
| 11 | 440000005 | 32 | 26.2 | 2.9 | 0.539 | 0.26 | 60 | 23 |
| 11 | 440000004 | 40 | 32.6 | 3.7 | 0.835 | 0.41 | 40 | 23 |
| 11 | 440000009 | 50 | 40.8 | 4.6 | 1.307 | 0.62 | 20 | 28 |
| 11 | 440000010 | 63 | 51.4 | 5.8 | 2.075 | 0.98 | 12 | 30 |
| 11 | 440000011 | 75 | 61.4 | 6.8 | 2.961 | 1.34 | 12 | 23 |
| 11 | 440000012 | 90 | 73.6 | 8.2 | 4.254 | 2 | 8 | 20 |
| 11 | 440000013 | 110 | 90 | 10 | 6.362 | 2.9 | 4 | 27 |
| 11 | 440000014 | 125 | 102.2 | 11.4 | 8.203 | 3.8 | 4 | 20 |
| 11 | 440000016 | 160 | 130.8 | 14.6 | 13.437 | 6.3 | 4 | 12 |
REPOLEN PP-R DRINKING WATER pipes are the best system for the transport of hot and cold water under pressure, for human consumption. They are manufactured with Polypropylene Copolymer Random type 3, a copolymer of propylene and ethylene. They have exceptional mechanical resistance up to 100ºC and below 0º and excellent chemical resistance. The REPOLEN PP-R BANDA AZUL pipe is a monolayer pipe designed to provide solutions in all those applications that require the transport of water under pressure for consumption.
They share the properties of REPOLEN PP-R pipes, with innumerable uses. However, REPOLEN PP-R DRINKING WATER pipes are specially designed for hydro-sanitary installations (connections, meter and collector panels, risers, distribution, branches, boilers, accumulators, return lines), since the blue line indicates that they are drinking water pipes. This small aspect simplifies the installation process, since it is easier for construction companies to identify the pipes and their applications when different fluids are installed in the same space. In addition, the blue lines are used to align the fittings, acting as a reference point.
PROJECTS
REPOLEN PP-R DRINKING WATER pipes are manufactured in compliance with UNE EN ISO 15874 and are certified by AENOR (No. 001/005595). This type of pipe, made of polypropylene, is notable for its high chemical resistance, making it ideal for withstanding acids, alkalis, and numerous industrial substances. However, it is important to keep in mind that PPR material is not suitable for prolonged exposure to sunlight, as this accelerates aging and deterioration. For situations where direct sunlight is required, we offer multi-layer PPR pipes specifically designed with UV protection to ensure durability.
Drinking water pipes cannot be manufactured with recycled materials, according to regulations. We use environmentally friendly and 100% recyclable materials, due to our strong environmental commitment. All our PPR pipes are made from virgin raw materials. REPOLEN PP-R DRINKING WATER pipes are available in SDR11 in a wide variety of diameters, from 20 mm to 160 mm.
